Cotton manufacture: a manual of practical instruction in the processes of opening, carding, combing, drawing, doubling, and spinning of cotton, and the methods of dyeing and preparing goods for the market (1894)

Lister, John, 1920- · London, C. Lockwood · leaf 204

An illustration from Cotton manufacture: a manual of practical instruction in the processes of opening, carding, combing, drawing, doubling, and spinning of cotton, and the methods of dyeing and preparing goods for the market, 1894, leaf 204
e heald levers. A correspondingseries of levers is at the bottom of the loom, having their fulcrumsin the centre, the same as the heald levers, and at one end the healdlevers have a direct communication with the bottom ones by cords.A positive movement being thus secured throughout the two… … THE POWER LOOM. 191 We give in Fig. 66 a neat illustration of an excellent type of thisclass of machines, known as the Catlow dobby. The single lift isworked from the crank shaft, allowing the healds to be brought to alevel at each pick of the shuttle. The double-lift dobby, with onebarrel, has an…

Cotton manufacture

Internet Archive · UMass Dartmouth, Claire T. Carney Library · Public Domain Mark 1.0. Free to use for anything.
