g. 21 shows the gears from A to K which drive thebottom rolls, and also shows the gears from a to f whichdrive the spindles. Fig. 22 shows the gears involved in driving the bobbins,lifting train, which traverses the bobbin rail up and down. All of the plans are lettered to correspond, so that… … 92 Twist gear B drives the top cone shaft, through gearsC and D. On the outer end of top cone shaft the gear E drivesthe front roll through gear F. On the front roll is small pinion G, which drives crowngear H. Crown gear H is on a stud which carries the draft gearJ on the other end. Draft gear J…
