A laboratory course in experimental physics (1896)
Loudon, W. J. (William James), McLennan, John Cunningham, joint author · New York and London, Macmillan and Co. · leaf 268
and their resistance deter-mined by one of the methods outlined in the last experiment. If, however, a second instrument is not at hand or is notconveniently adjusted, either the method of equal deflectionsor that known as Thomsons may be applied, and in thesetests, the galvanometer whose… … Fig. 42. going through the galvanometer G, and part through a shunt5. The main circuit also contains a variable resistance AB. 254 EXPERIMENTAL PHYSICS. Denoting the resistance of the galvanometer by g, that of theshunt by s, and that of the battery and leading wires by r,we have, when the…
Physics
Internet Archive · Cornell University Library · Public Domain Mark 1.0. Free to use for anything.
