Fig. 20. — Full Frame House. a, aill; &, corner post; c, brace; d, stud; e, head; /.stool; (?, plate; A, floor joists; k,common rafters; m, jack rafters ; n, hip rafters; o, double studs; p, mortised joint; r, openmortised joint; s, mortised joint, drawbored; t, end of rafters for box cornice;… … Fig. 21. — Balloon Frame. a, ribband, or ledger; 6, wall bridging; c. H balloon brace; d, 2 x 4 balloon brace;e, sawed lookouts spilied to the rafter; /, brick noggin. 25 26 CONSTRUCTIVE CARPENTRY posts, girts, and often the braces are concerned, thoughthe last are frequentlj^ of the balloon type,…
