ide bar, and the direction ofmotion, refer to the go-ahead state of the gear. As the crankshaft rotates, D moves along the guide bar ST, and E describesa closed oval as sketched. If the guide bar is tUted over tothe dotted position, the path of E becomes the dotted oval. For further information,…
