ssions, the first term represents the primaryeffect, that is to say, the effect of the crank arm alone when obliquityis neglected; the second term represents the secondary effect,that is to say, the effect (very approximately) of the obliquity ofthe rod. At the two ends of the stroke the… … Fio. 289. , (Fig. 289) a circle having a radius equal to the crank radius, andalso two smaller circles touching each other at P, with their centres. El and Eg, on the line of stroke produced, and of radii equal to - the n crank radius. Then, if AP represent the centripetal acceleration of the crank…
