Thomälen, Adolf, 1865-, Thomälen Adolf. Kurzes Lehrbuch der Electrotechnik. English · London, E. Arnold · leaf 146
The others are clearly indicated by means of the letters onthe segments. The arrows are now drawn on the front end-connections. Assuming thatthe coils I—/[ and 9—12, lying in the neutral zone, are short-circuited at the 48. Two-circuit Drum-winding 131 + moment chosen, we get the position for the… … As before, the slot-winding with two coil-sides per slot is extremelysimple. After going once round the armature, that is, after zp steps, wearrive at the slot next to that from which we started. The result is thesame as when, in a smooth-cored armature, we arrive at the coil-side nextbut one to…
Electrical engineering
