Fig. 209.—The G. V. Gnome Monosoupape Nine-Cylinder Rotary EngineMounted on Testing Stand. in length and weighing about 97 pounds. The first opera-tion is to drill a 21A6 inch hole through the center of theblock. A heavy-duty drilling machine performs this 488 Aviation Engines … Gnome Monosoupape Engine 489 work, then the block goes to the lathe for further opera-tions. Fig. 211 shows six stages of the progress of acylinder, a few of the intermediate steps being omitted.
