Mechanics of engineering (solids) : comprising statics and kinetics of solids, and the mechanics of the materials of construction, or strength and elasticity of beams, columns, shafts, arches, etc. : for use in technical schools (1911)
Church, Irving P. (Irving Porter), 1851-1931 · New York : Wiley ; London : Chapman & Hall · leaf 264
sses; i, (6.) E,^E,; (7.) The dimensions of the cross-section are small com-pared with the length of the piece ; (8.) There is no shear perpendicular to the force plane,on internal surfaces perpendicular to that plane. In the locality where any one of the external forces Isapplied, local stresses… … Pig. 246 MECHAH^ICS OF ENGINEERING. ■weight of the beam), viz.: Pi, P^, and P3. Pj and Pj areloads, P2 the reaction of the support. The force plane is vertical. N^L is the neutral line orelastic curve. NA is the neutral axis of the cross-sectionat m; this cross-section, originally perpendicular to…
Mechanics, Applied · Strength of materials
Internet Archive · Cornell University Library · Public Domain Mark 1.0. Free to use for anything.
