Mechanics of engineering. Comprising statics and dynamics of solids: and the mechanics of the materials of constructions, or strength and elasticity of beams, columns, arches, shafts, etc (1888)
Church, Irving P[orter], 1851- [from old catalog] · New York, J. Wiley & sons · leaf 258
tresses ; (6.) Ft=Ec; (7.) The dimensions of the cross-section are small com-pared with the length of the piece ; (8.) There is no shear perpendicular to the force planeon internal surfaces perpendicular to that plane. In the locality where any one of the external forces isapplied, local stresses… … Fig. 221. 246 MECHANICS OF ENGINEERING. weight of the beam), viz.: Plt P2, and P3. Px and P3 areloads, P2 the reaction of the support. The force plane is vertical. NYL is the neutral line orelastic curve. NA is the neutral axis of the cross-sectionat m ; this cross-section, originally perpendicular…
Mechanics, Applied · Engineering · Strength of materials
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
