A practical course in wooden boat and ship building, the fundamental principles and practical methods described in detail, especially written for carpenters and other woodworkers who desire to engage in boat or ship building, and as a textbook for schools (1918)

Van Gaasbeek, Richard Montgomery, 1877- · Chicago, F. J. Drake & company · leaf 141

An illustration from A practical course in wooden boat and ship building, the fundamental principles and practical methods described in detail, especially written for carpenters and other woodworkers who desire to engage in boat or ship building, and as a textbook for schools, 1918, leaf 141
agonals are connected to the top belt bytwo %-iiicli rivets and at each crossing by one1-inch rivet, and also fastened to each frame timberby one 1-inch countersunk bolt. They should becarried well down and wrapped around the bilgefar enough to overlap the ends of the floor timbers. The iron straps… … Figure 84.—Bow of Ship Ready for Planking. illustrations to get the general layout of the shipbefore planking and in the finished state. 138 PLANKING AND FINISHING 139 Figure 84 shows the bow of a ship ready for.planking. Figure 85 shows the same bow planked,with the staging still in position.…

Shipbuilding

Internet Archive · Cornell University Library · Public Domain Mark 1.0. Free to use for anything.
