we wish to get a perspective representation of thisline AB, we repeat these conditions on our perspectivedrawing. We set off the distance M from the centreline, along the ground-line, towards the left. We nextset off the angle T at the directing line, and so obtainthe far end of our line, namely… … Ni EYE Fig. i7.—Oue line crossing another, and bo indicating a measurementupon it. did that of AB. That is to say, we set off the distanceN from A on the ground-line toward the right. Thisgives us point C. We then draw a vanishing parallel forBC, that is, we set up the angle X from the…
