figr.^S BENT RIB ROOF TRUSSES 119 the complete stress diagram, Fig. 385, to one-third the scale of the othersmay be constructed. The effect of the additional members will he toavoid bending moments on the joints A, B and C, the bending momentswhen they are removed being equal to the stress in the… … multiplied by the perpendicular distance to the neutral axis of the joint,and so far it is assumed that no stress is taken by the joints D and E.Next, assuming that the joints A, D, and E take the stress, the framediagram will have to be as in Fig. 392, and the corresponding stress
