Radford's portfolio of details of building construction; a remarkable and unique collection of full-page plates, accurately drawn and reproduced to exact scale. Complete details for every style of interior trim, including special built-in features (1911)

Radford, William A., 1865- ed, Johnson, Bernard L., joint ed, Rawson, Charles P., joint ed · Chicago, Ill., The Radford Architectural Company · leaf 118

An illustration from Radford's portfolio of details of building construction; a remarkable and unique collection of full-page plates, accurately drawn and reproduced to exact scale. Complete details for every style of interior trim, including special built-in features, 1911, leaf 118
DtTftlL Of^ </£sr/Bt/LE. PLATE 104—CONSTRUCTION AND FINISH FOR SUMMER RESIDENCE Complete details of interior trim; also details of classic porch shown on floor plan sketch, Plate102. For additional details of this house, see Plates 102, 103 and 105. 115 … CLE.y.!?- 5£CT OF- APLATE 105—WALL SECTION AND CONSTRUCTION FOR SUMMER RB&IDENCE Details of exterior construction of large elaborate summer residence, main floor plan ot which isshown in Plate 102. For additional details of this design see Plates 102, 103 and 104. 116 TIN eooFv I7ETAIL 0…
