Radford's portfolio of details of building construction; a remarkable and unique collection of full-page plates, accurately drawn and reproduced to exact scale. Complete details for every style of interior trim, including special built-in features (1911)

Radford, William A., 1865- ed, Johnson, Bernard L., joint ed, Rawson, Charles P., joint ed · Chicago, Ill., The Radford Architectural Company · leaf 169

An illustration from Radford's portfolio of details of building construction; a remarkable and unique collection of full-page plates, accurately drawn and reproduced to exact scale. Complete details for every style of interior trim, including special built-in features, 1911, leaf 169
V6RTICAt_ SECTION AT HEAD Pl-AN SECTION AT SIDE CASlNSr SHOvAn* OOOK HAN&ER AND RAIU SHOWING- Sf^CE FOR DOOR TO SLIDE PLATE 154^DETAILS OF SPECIAL DOOR COKSTRUCTION Working drawings of sliding door showing details of partition studding and of door hanger and rail.Details are also shown for… … 9o^

Building

Internet Archive · Cornell University Library · Public Domain Mark 1.0. Free to use for anything.
