Radford's portfolio of details of building construction; a remarkable and unique collection of full-page plates, accurately drawn and reproduced to exact scale. Complete details for every style of interior trim, including special built-in features (1911)

Radford, William A., 1865- ed, Johnson, Bernard L., joint ed, Rawson, Charles P., joint ed · Chicago, Ill., The Radford Architectural Company · leaf 33

An illustration from Radford's portfolio of details of building construction; a remarkable and unique collection of full-page plates, accurately drawn and reproduced to exact scale. Complete details for every style of interior trim, including special built-in features, 1911, leaf 33
PLATE 21—WALL SECTIONS AND SILL CONSTRUCTION Approved construction for the twelve leadingtypes of building, using the various common ma-terials: stucco on frame, rough boards on frame, cement block veneer, brick, cement blocks, boardsand batton on frame, shingles on frame, siding onframe, and brick… … ffA/r/ao

Building
