Fig. 271 EXERCISE SHEET CXH !216) With the siin as the source of light, determine the shade line andshadows, also the shadows on H and V, for the doublercurved surfacein Fig. 272. … Fig. 272 APPENDIX 309 EXERCISE SHEET CXUI (§316) With the sun as the source of light, determinethe shade line and shadows, also the shadows onH and V, for the baluster in Fig, 273. Placethe center of the base on H, 1 — 6 from Vand 1 — 6 from the left border line. Scale,3 = 1 — 0. EXERCISE SHEET…
