bottle is alsofilled about two-thirds full. The capbeing screwed on, the barometer canbe righted, when the flexible leathei*will allow the atmospheric pressure tobe communicated to the air inside, andso act upon the mercury in the bottleas if it were open to the atmosphere.Another feature of the… … Fig. 2. Sometimes the tube of a barometer is bent round at thelower end and formed into a glass cup (as in fig. 3), and inanother kind there is-no cup but a simple U-tube (fig. 4). In thiskind there is a float placed in the open tube, which actuates asmall pulley, carrying an index like a pressure…
