Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1910)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The N. W. Henley publishing company · leaf 293

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1910, leaf 293
761. C R A N E T R U C K. One of the handy things in a shop or warehouse. Withwindlass chain and block two tons may be hftedand easily wheeled over the floor. … 762. CENTRIFUGAL SEPARA-TOR. The perforated basket and loadare hung on the spindle. E is a cup-shaped pulley, inside of which is a ball-socket journal box. The step bearing, h, a,is also a ball socket in a spherical foot, bear-ing upon a spherical base with a flangeon its rim to hmit the eccentric…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
