An elementary treatise on mechanics for the use of the junior classes at the university ... With a collection of examples (1863)

Parkinson, Stephen, 1823-1889 · Cambridge [Eng.] Macmillan · leaf 43

An illustration from An elementary treatise on mechanics for the use of the junior classes at the university ... With a collection of examples, 1863, leaf 43 — 32 OF FOiiCES ACTING IN ONE PLANE. Let A, B be two points throughwhich the forces P, Q act, G apoint in the line AB through whichthe resultant B passes. Take any point 0 and throughit draw Ohca at right angles tothe directions of the forces; thensince the resultant of P, Q passesthrough G,…

Mechanics

Internet Archive · Cornell University Library · Public Domain Mark 1.0. Free to use for anything.
