The microscopy of vegetable foods : with special reference to the detection of adulteration and the diagnosis of mixtures (1906)
Winton, Andrew Lincoln, 1864-1946, Moeller, Josef, 1848-1924 · New York : John Wiley & Sons · leaf 599
V—I Fig. 492. Vanilla. Outer layers of fruit in surface view, ep epitarp with v crystals ofcalcium oxalate; /> parenchyma. X160. (Moeller.) of thin-walled, elongated elements. On the surface between the mem-bers of each pair of placentae, the epidermal and subepidermal layers … Fig. 493. Vanilla. Longitudinal section of fruit flesh, p parenchyma with 0 raphides;sp spiral vessel; n pitted vessel. X160. (Moeller.) are made up of longitudinal bundles of thread-like mucilaginous cellswhich serve as a conducting tissue for the pollen tubes. They havebeen studied by Busse,…
Plant anatomy · Food adulteration and inspection · Microscopy
Internet Archive · Cornell University Library · Public Domain Mark 1.0. Free to use for anything.
