Cyclopedia of applied electricity : a general reference work on direct-current generators and motors, storage batteries, electrochemistry, welding, electric wiring, meters, electric lighting, electric railways, power stations, switchboards, power transmission, alternating-current machinery, telegraphy, etc. (1916)
American Technical Society · Chicago : American Technical Society · leaf 47
tallic combs. The two knobs R and Shave their capacity increased by the Leyden jars L and L/ The action of the machine is best understood from the diagram(Fig. 34). Suppose that a small + charge is originally placed on theinductor C D. Induction takes place in the metallic system consistingof the… … Fig. 34. Illustrating Action of Static Machine. carried over tothe position w, where a part of it passes over to the inductor A B, thus charg-ing it negatively. When I reaches the position n, the remaindel 37 28 ELECTRICITY AND MAGNETISM of its charge, being repelled by the negative which is now on…
