Cyclopedia of applied electricity : a general reference work on direct-current generators and motors, storage batteries, electrochemistry, welding, electric wiring, meters, electric lighting, electric railways, power stations, switchboards, power transmission, alternating-current machinery, telegraphy, etc. (1916)
American Technical Society · Chicago : American Technical Society · leaf 187
eries-Wound Generator and hence zero field-exciting current, an e. m. f. is generated in thearmature of small value, as already explained. Thus a series gen-erator is self-starting as regards generation of voltage. Relation between Magnetization Curve and Total CharacteristicCurve of a Series-Wound… … Fig. 163. Diagram of Connections for aShunt-Wound Generator cal with the magnetization curve. The effect of the armature cur-rent is, how^ever, either to reduce inducing flux and therefore thegenerated voltage which corresponds to a given field-exciting current,or to necessitate an…
Electrical engineering
Internet Archive · Northeastern University Library · Public Domain Mark 1.0. Free to use for anything.
