ternal Construction 169 48 MANAGEMENT OF DYNAMO-ELECTRIC MACHINERY position, the exact point of synchronism; and hy its direction ofrotation, whether the incoming machine is running too slow ortoo fast. Lamps are usually provided with this instrument as acheck on its operation and for use in case… … Si^nchr-on/sm /ncf/CQ^or-— Gr~ounct Seises P/utjs St art, /n^ /funn/na //O Wo/ts //O \/b/ts Fig. 44. Wlrina; Diagram for Synchronism Indicator with Potential Transformers,Secondaries Grounded. Synchronism Is Indicated When the Lamps Are Dark Figs. 44 and 45 show two methods of connecting a…
