Cyclopedia of applied electricity : a general reference work on direct-current generators and motors, storage batteries, electrochemistry, welding, electric wiring, meters, electric lighting, electric railways, power stations, switchboards, power transmission, alternating-current machinery, telegraphy, etc. (1916)
American Technical Society · Chicago : American Technical Society · leaf 154
Fig. 124. Arrangement of Slots for Three-Phase Alternator Armature up as, etc.for winding C. The windings A, B, and C here described are of the concen-trated type, having only one slot per pole for each winding. Dis- 134 ALTERNATING-CURRENT MACHINERY 123 … Portion of Diagram of Windings forThree-Phase AlternatoV Armature tributed windings also are frequently used for three-phase alter-nators. Thus Fig. 125 shows a portion of a three-phase armaturewith its A, B, and C windings each distributed in two slots perpole. The coils belonging to windings A,…
Electrical engineering
Internet Archive · Northeastern University Library · Public Domain Mark 1.0. Free to use for anything.
