nce. The usual method of allowing for it is to consider thatthere is a certain amount ofresistance per ton per degreeof curvature, say 0.7 pound.The number of degrees ofcurvature is the angle be-tween two radii of the curvedrawn at the ends of a chord100 feet in length. In termsof the radius r, the… … Fig. 129. Graphical Determination of TrackCurvature 100 feet? As explained above, sine of ^ the angle=^^ = | From the table of sines w^e find that this is the sine of 30°. The angle ofcurvature is, therefore, 60°. (b) What additional resistance is caused by this curvature? 7^=0.7X60=42 pounds per…
