Cyclopedia of applied electricity : a general reference work on direct-current generators and motors, storage batteries, electrochemistry, welding, electric wiring, meters, electric lighting, electric railways, power stations, switchboards, power transmission, alternating-current machinery, telegraphy, etc. (1916)

American Technical Society · Chicago : American Technical Society · leaf 130

An illustration from Cyclopedia of applied electricity : a general reference work on direct-current generators and motors, storage batteries, electrochemistry, welding, electric wiring, meters, electric lighting, electric railways, power stations, switchboards, power transmission, alternating-current machinery, telegraphy, etc., 1916, leaf 130
STARTING^RESISTANCE ^^f a -=mE^ FIELD DISCHARGERESISTANCE The closing ofeither ouxiEiari/switch trips circuitbreakers. … MOTOR Fig. 10. Layout for Fool Proof Switchboard Panel for Motor Equipment in Large MillCourtesy of General Electric Company It is impossible, with this panel, to do anything which would causetrouble or injure the motor or the starting equipment. Arrangement of Boards. There is but little chance…

Electrical engineering

Internet Archive · Northeastern University Library · Public Domain Mark 1.0. Free to use for anything.
