Morton, Edward Reginald, 1867- · New York : E.B. Treat & Co. · leaf 45
RSS S£Nl£S WOUND DYNAMO Fig. 6. … SHUNT WOUND DYNAMO Fig. 7. opposite points, and the ends connected one to each of twoslip rings which are also insulated from the shaft andfrom each other, and by means of brushes the alternatingcurrent generated in the armature is collected. In thecase of a very small alternator, one or more…
