Cyclopedia of applied electricity : a general reference work on direct-current generators and motors, storage batteries, electrochemistry, welding, electric wiring, meters, electric lighting, electric railways, power stations, switchboards, power transmission, alternating-current machinery, telegraphy, etc. (1916)

American Technical Society · Chicago : American Technical Society · leaf 339

An illustration from Cyclopedia of applied electricity : a general reference work on direct-current generators and motors, storage batteries, electrochemistry, welding, electric wiring, meters, electric lighting, electric railways, power stations, switchboards, power transmission, alternating-current machinery, telegraphy, etc., 1916, leaf 339
Fig. 73. Wiring Diagram for Using EdisonRectifier … Fig. 7^_. 302 STORAGE BATTERIES 95 the south end. This reverses the connection of the alternating-cur-rent to the direct-current circuit, but as the direction of the currenthas also reversed, the current flows in the same direction as before.This rectifier can be operated on any 60-cycle circuit of…

Electrical engineering

Internet Archive · Northeastern University Library · Public Domain Mark 1.0. Free to use for anything.
