Cyclopedia of architecture, carpentry, and building : a general reference work ... (1907)
American School of Correspondence · Chicago : American Technical Society · leaf 438
Fig. 37. Finding- Length of Rafter for Front Wing in Hoof Shown in Fig. 36. … Fig. 3». Laying Out Timbers of Roof Shown in Fig. Sfi, hy Projecting Slope of Koof into Horizontal Plane. 17 feet, and this will be the exact length of the rafter for a roof rising12 inches to the foot run and having a run of 12 feet. The length of the rafter for the front wing, which has a run of…
Architecture · Building · Carpentry
