ICS 31 force exerted on the joint by member 84; since the force actsaway from the joint it is a pull and the member is in tension.DA (0.87 inches == 5,220 pounds) represents the force exertedupon the joint by the member 36; since the force acts away fromthe joint, it is a pull and the member is in… … stress in the corresponding one on the left-hand side; hence furtheranalysis is unnecessary. 2. It is required to analyze the truss represented in Fig.20 (ff), the truss being supported at the ends and sustaining twoloads, 1,800 and 600 pounds, as shown. (For simplicity we as-sumed values of the…
