The elements of the mechanics of materials and of power transmission (1911)
King, William Richard, 1852- · New York, J. Wiley & sons; [etc., etc.] · leaf 164
itude and direction the stresses in the mem-bers CD and DB. The arrows within the triangle bed show the 154 THE ELEMENTS OF MECHANICS OF MATERIALS direction of these stresses, and they are marked with arrowheadsaccordingly in the frame diagram. By scale measurements ofthe reciprocals the stresses… … Ri= 3 tons Ro=3 tons Fig. 97. To draw the reciprocal of the joint ABED at the ridge wemeasure ah downward, and make it 1.5 inches long to represent,to the chosen scale of 0.25 inch to the ton, the magnitude anddirection of the external force of 6 tons. The stress in therafter AD has been found to…
Mechanics, Applied · Power transmission
