)oint v/i^ (diagram A) to the 204 … 36 SHADES AND SHADOWS curve. The point of intersection, 10^, is the shadow of the end ofthe edge C. It is also the beginning of the shadow of the edge Bon the right-hand slope, which shadow is parallel to B. The remaining shadows of the pediment are found in thesame manner, and may be understood,…
