Skinner, Frank W. (Frank Woodward), 1858-1932 · New York, McGraw · leaf 127
■II4.0C.C Beornn^., - 1160over Angles 1 Panels af I43= 9996 Potne/s oif I43= Q56 nojle Splice … Lateral Bracing and Arrangement of Splices. — West Shore Bridge 454. about 108 ft. clear span which carries two tracks over theErie Canal at a point about 24 miles west of Jordan. It hastwo plate girders 10 ft. deep from back to back of flangeangles, 15 ft. 4 in. apart on centers, and 116 ft. long…
Bridges
