steam circuit system; or may becarried down the middle of the building, with long branches extendingto the risers near the walls, it being assumed that-the radiators will belocated near the exposed parts of the building. The mains and branches should pitch down toward the risers,permitting the air… … Fig. 105. Showing the Mains and Branches Pitched Down Towards the Risers fittings used for first-class work, although, if the piping is generouslyproportioned, standard fittings will answer. A hot-water thermome-ter should always be placed on the boiler or near it, in the flow-main. Radiator…
