Cyclopedia of architecture, carpentry, and building : a general reference work (1912)
American Technical Society · Chicago : American Technical Society · leaf 164
Fig. 45. Screw Pile. Fig. 46. Disc Pile. of steel for sheet piling are nearly all patented. The cross-sectionsof a few of them are shown in Fig. 44. One feature of some of thedesigns is the possible flexibility secured in the outline of the damwithout interfering with the water-tightness. Sheet… … Fig. 48. Single and Sheet PilingPlan View. prevent the materials of a foundation from spreading, or to guard afoundation from being undermined by a stream of water. To makewooden piles drive with their parts close against each other, they arecut obliquely at the bottom, as shown in Fig. 49. They…
Architecture · Building
Internet Archive · Kelly Library, University of Toronto · Public Domain Mark 1.0. Free to use for anything.
