ckets or similar riveted members occui on agirder, it is better to give a separate section for the details of rivetingof these members. Tiie end view, and sections A, B, C, and D, showthe details for these brackets supporting the stonework, and show thevarious details necessary to conform to the… … to 282 STEET> CONSTRUCTION supporting column, to provide for the shear; and tliese stiffenersshould be fitted to top and bottom flanges. PROBLEMS^lake a complete shop detail, at a scale of f inch to 1 foot, of asingle-web plate girder 30 feet long clear span, resting on a brick wallat each end…
