. 150 shows a framework ofthree pieces, two at right anglesand a slanting brace. The hori-zontal piece is mortised into theupri^ht,as indicated by the dottedlines. In Fig. 151 the isometric out-line of a house is represented,showino; a dormer window and apartial liip roof; a h is a hip rafter,c d… … V Fig. 148. Isometric of a Cylinder
