Blueprint reading; a practical manual of instruction in blueprint reading through the analysis of typical plates with reference to mechanical drawing conventions and methods, the laws of projection, etc (1919)

Fairfield, Howard Parker, 1858-, Kenison, Ervin, Waite, Edward B. (Edward Broughton), 1873-, American Technical Society · Chicago, American technical society · leaf 261

An illustration from Blueprint reading; a practical manual of instruction in blueprint reading through the analysis of typical plates with reference to mechanical drawing conventions and methods, the laws of projection, etc, 1919, leaf 261 — ones. In woodwork,mortises and joints and variousparts of framing are well shownin isometric. This system is usedalso to give a kind of birds-eyeview of mills or factories. It is alsoused in making sketches of smallrectangular pieces of machinery,where it is desirable to give shapeand dimensions in… … y Fig. 157. Isometric of a Cylinder 182 MECHANICAL DRAWING 117 exact construction of which would necessitate finding a numberof points; for this reason an approximate construction by arcs ofcircles is often made. In the method, Fig. 156, four centers areused. Considering the upper face of the cube,…

Mechanical drawing · Blueprinting

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
