How a skylight is shown. Fig. 93—Skylight on first Fig. 94—Skylight on second floor. floor. of this extension from the front portion of the build-ing. The gutter for the main building is also situ-ated at the rear discharging on the roof of the exten-sion thru a 5 leader which is shown by a… … Fig. 95—How leaders are shown on elevation. EL, and the leader from this is also shown on theplan of the lower floor, Fig. 93. Leaders are sometimes drawn on the elevationsas shown in Fig. 95, in which A shows the gutter,B the elbow connecting the down spout with theleader and C the leader, D is a…
