Fig. 135. Double Hanger with Joists in Place … Fig. 136. Patent Hanger with Joists in Place Fig. 137. Joists Framed into Sill If the joists are flush with the girder on top, and are framed into thesill in the ordinary way, as shown in Fig. 137, the girder can not beflush on top with the sill; while, on the other hand, if the girder isflush with…
