on top with the sill; while, on the other hand, if the girder isflush with the sill on top, it can not at the same time be flush withthe joists on top. If joist hangers are used on the girder to support 107 96 CARPENTRY the joists, they will probably be used on the sill as well, as explainedin… … Fig. 138. Method of Bringing Joist Level When Resting on Sill as shown in Fig. 138. If the girder were framed into the sill at all, itwould almost always be made flush with the sill on top, and by theproper adjustment of the hangers the joists would be arranged so asto be level. For framing the…
