Cyclopedia of locomotive engineering, with examination questions and answers; a practical manual on the construction care and management of modern locomotives (1916)
Swingle, Calvin Franklin, 1846- [from old catalog] · Chicago, F. J. Drake & co., pub. for Sears, Roebuck & co. · leaf 371
Monitor, Interior View the spindle outside the steam chamber, diminishing itswear. The packing can be adjusted and tightened bymeans of a large central nut, still preserving the sim-plicity and convenience of an ordinary stuffing box. The water valve has been provided with a doublehandle wJth index… … INJECTORS, STEAM GAUGES, ETC. 367 Description of 88 Monitor, Fig. 168. This injector isa modification of the well-known locomotive injectorof that name, and is designed to supply the demand fora lever-handled injector, and embody in a new combina-tion all the best qualities of the former…
Locomotives
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
