Cyclopedia of locomotive engineering, with examination questions and answers; a practical manual on the construction care and management of modern locomotives (1916)
Swingle, Calvin Franklin, 1846- [from old catalog] · Chicago, F. J. Drake & co., pub. for Sears, Roebuck & co. · leaf 67
K— > Figure 21 … the net strip or section of plate, the strength of whichis 59,062 and the efficiency = 59,062 x 100 * 85,312 =69.2 per cent. ?. THE BOILER 67 A double-riveted butt joint is illustrated by Fig. 21,and the dimensions are as follows: P, inner row of rivets = 2^ in. P, outer row of rivets = 5*^ in. T…
Locomotives
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
