An illustration from Twentieth century hand-book for steam engineers and electricians with questions and answers; a practical non-technical treatise .., 1913, leaf 110
two rivetsand shearing one. The resistance is represented by 2D XTXC+IAXS; expressed in figures, 1X^X.4375X95,000+.7854X45,000=118,468. The strength of a solid strip of plate 51/^ inches widebefore drilling is PXTXT.S., or 5.5X.4375X60,000=144,375, and the efficiency of the joint is… … Fig. 35triple riveted butt joint Failure may occur in this joint in either one of five ways. 1. By tearing the plate at the outer row of rivets wherethe pitch is 6% inches. The net strength of the unit stripat this point is P—DXTXT.S., found as follows: 6.75—.9375X.4375X60,000=152,578. 98 * Steam…
