e in the pressure chamber is reducedenough below that in the brake pipe to cause the dif-ference in pressure on the two sides of piston 26 tcforce it and graduating valve 28 to the left until theshoulder on the piston stem strikes the right-hand end ofslide valve 31, the position indicated in Fig.… … I CHAMBER. ^ I ^////////M////////////////////^> FIG. 303. SERVICE LAP 686 LOCOMOTIVE ENGINEERING and it also has closed port s, cutting off communicationto the safety valve. The flow of air past applicationvalve 5 to the brake cylinders continues until their pres-sure equals that in the…
