Cyclopedia of locomotive engineering, with examination questions and answers; a practical manual on the construction care and management of modern locomotives (1916)
Swingle, Calvin Franklin, 1846- [from old catalog] · Chicago, F. J. Drake & co., pub. for Sears, Roebuck & co. · leaf 75
Vertical Section A-B. … End Elevation,Sfowing Attachment of bong. Stays. Half Section C-D. Half End Elevationof Smoke-Box. Figure 28 or distance in inches between centers of the pointsof connection of the stays to the flat plate. Thus,suppose the stays in a certain boiler are spaced 8 in.apart, the area sustained by each…
Locomotives
