Journal - Franklin Institute of the State of Pennsylvania (1826)
Franklin Institute, Philadelphia, Franklin Institute (Philadelphia, Pa.) · [Philadelphia : Franklin Institute] · leaf 320
and E F, show the air chamber, the gas cham-ber with the tubes at the top of it, and the outside casing. The action is as follows: The gas passes into its chamber from thepipe at the bottom of the burner, thence up the tubes, meeting at the Oct., 1884.J Siemens Regenerative Gas Burners. 299 point… … and slightly inwards, around and over the top of the porcelain cylin-der, down into the regeneratoi*, tiience, through the lateral pipe, to thechimney. The heat tiius generated is absorbed in its passage through the 300 Siemens Regenerative Gas Burners. [Jour. Frank. Inst., regenerator, and is in…
