Modern locomotive engineering, with questions and answers .. (1913)
Swingle, Calvin Franklin, 1846- [from old catalog] · Chicago, F. J. Drake & co · leaf 81
Vertical Secfion A-B. … End Elevation,SftovringAnachnient of bong. Stays. H— »«—I Half End EtevcrtionHalf Secfion C-D. i of 5nwke-Bo». Figure 28 or distance in inches between centers of the pointsof connection of the stays to the flat plate. Thus,suppose the stays in a certain boiler are spaced 8 in.apart, the area…
Locomotives
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
