Cyclopedia of locomotive engineering, with examination questions and answers; a practical manual on the construction care and management of modern locomotives (1916)
Swingle, Calvin Franklin, 1846- [from old catalog] · Chicago, F. J. Drake & co., pub. for Sears, Roebuck & co. · leaf 90
Figure 34 tlr:s dividing it into two branches to which the steampipes are connected. These connections, which are all within the amoke-box, are clearly illus-trated in Fig. 31, towhich reference isnow made. The steam pipes Iand 2 are connectedto each of the twobranches of the T-pipe at their…
Locomotives
